型号 |
线径 |
颜色 |
坯料 |
最大绝 |
螺栓 |
外形尺寸 In. |
包装 |
||
厚度 |
缘直径 |
尺寸 |
L |
W |
C |
||||
PV22-2R-CY |
26-22 |
黄色 |
0.02 |
.110 |
#2 |
0.68 |
0.21 |
0.18 |
100 |
PV22-4R-CY |
0.02 |
.110 |
#4 |
0.68 |
0.21 |
0.18 |
100 |
||
PV22-6R-CY |
0.02 |
.110 |
#6 |
0.68 |
0.21 |
0.18 |
100 |
||
PV22-8R-CY |
0.02 |
.110 |
#8 |
0.78 |
0.26 |
0.26 |
100 |
||
PV22-10R-CY |
0.02 |
.110 |
#10 |
0.78 |
0.32 |
0.24 |
100 |
||
PV18-4R-CY |
22-18 |
红色 |
0.03 |
.150 |
#4 |
0.84 |
0.25 |
0.22 |
100 |
PV18-6R-CY |
0.03 |
.150 |
#6 |
0.86 |
0.25 |
0.22 |
100 |
||
PV18-8R-CY |
0.03 |
.150 |
#8 |
0.91 |
0.31 |
0.26 |
100 |
||
PV18-10R-CY |
0.03 |
.150 |
#10 |
0.94 |
0.31 |
0.27 |
100 |
||
PV18-14R-CY |
0.03 |
.150 |
1/4" |
1.11 |
0.46 |
0.39 |
100 |
||
PV18-56R-CY |
0.03 |
.150 |
5/16" |
1.11 |
0.46 |
0.39 |
100 |
||
PV18-38R-LY |
0.03 |
.150 |
3/8" |
1.19 |
0.53 |
0.42 |
50 |
||
PV18-12R-LY |
0.03 |
.150 |
1/2" |
1.42 |
0.72 |
0.53 |
50 |
||
PV14-4R-C |
16-14 |
蓝色 |
0.03 |
.170 |
#4 |
0.84 |
0.25 |
0.19 |
100 |
PV14-6RN-C |
0.03 |
.170 |
#6 |
0.84 |
0.25 |
0.19 |
100 |
||
PV14-6R-C |
0.03 |
.170 |
#6 |
0.92 |
0.31 |
0.25 |
100 |
||
PV14-8R-C |
0.03 |
.170 |
#8 |
0.92 |
0.31 |
0.25 |
100 |
||
PV14-10R-C |
0.03 |
.170 |
#10 |
0.92 |
0.31 |
0.25 |
100 |
||
PV14-14R-C |
0.03 |
.170 |
1/4" |
1.12 |
0.46 |
0.38 |
100 |
||
PV14-56R-C |
0.03 |
.170 |
5/16" |
1.12 |
0.46 |
0.38 |
100 |
||
PV14-38R-L |
0.03 |
.170 |
3/8" |
1.21 |
0.53 |
0.43 |
50 |
||
PV14-12R-L |
0.03 |
.170 |
1/2" |
1.42 |
0.72 |
0.53 |
50 |
||
PV10-6R-L |
12-10 |
黄色 |
0.04 |
.225 |
#6 |
1.05 |
0.31 |
0.31 |
50 |
PV10-8R-L |
0.04 |
.225 |
#8 |
1.05 |
0.31 |
0.31 |
50 |
||
PV10-10R-L |
0.04 |
.225 |
#10 |
1.05 |
0.31 |
0.31 |
50 |
||
PV10-14R-L |
0.04 |
.225 |
1/4" |
1.23 |
0.52 |
0.38 |
50 |
||
PV10-56R-L |
0.04 |
.225 |
5/16" |
1.23 |
0.52 |
0.38 |
50 |
||
PV10-38R-L |
0.04 |
.225 |
3/8" |
1.31 |
0.58 |
0.41 |
50 |
||
PV10-12R-Q |
0.04 |
.225 |
1/2" |
1.46 |
0.72 |
0.53 |
25 |
